Viking Electronics 300TB-IP-EWP SIP/Multicast Talk-Back Paging Horn w/Enhanced Weather Protection (300TB-IP-EWP)

The Viking 300TB-IP-EWP Paging Horn with Talk-Back can be used for: standard one-way SIP endpoint paging, two-way conversations via SIP endpoint paging, one-way multicast paging, and making standard or emergency two-way SIP calls initiated from the optional auxiliary switch input. The microphone enables talk-back and also monitors room noise to automatically increase the speaker volume when necessary.

An optional auxiliary switch input allows a hard wired button or switch to initiate a SIP call. The button can be mounted on the wall or concealed under a desk, etc. A momentary button press will initiate a standard call, while holding the button for 3 or more seconds will initiate an emergency call.

The 300TB-IP-EWP features a high efficiency 6 Watt class D amplifier capable of driving the horn at up to 113 dB SPL at 1 meter.

The 300TB-IP-EWP is equipped with Enhanced Weather Protection (EWP), ideal for outdoor installations where the unit is exposed to precipitation or condensation. EWP products are designed to meet IP66 standards and may feature foam rubber gaskets, sealed connections, gel-filled butt connectors, as well as potted circuit boards with internally sealed, field-adjustable trim pots and DIP switches for easy on-site programming. For more information on EWP, see DOD 859.

Viking 300TB-IP-EWP SIP/Multicast Talk-Back Horn Features

Large 10-inch diameter horn
Fully adjustable mounting hardware included
Quick and easy installation
SIP compliant (see Viking 300TB-IP Product Manual for list of compatible IP-PBX phone systems)
PoE powered (class 3, <13 Watts)
Paging prioritization
Plays audio from standard multicast sources
SIP endpoint or multicast group member
Red call status LED indicator
Automatic Noise Canceling (ANC) feature for operation in noisy environments
Proprietary VOX switching eliminates the need for â€œPush to Talkâ€ mode
Selectable auto-answer feature for monitoring
Compatible with Polycom multicast paging
Built-in high-efficiency 6 Watt class D amplifier
SIP/Multicast: SIP page, SIP page and zoned multicast receive
Support for access code to prevent unwanted SIP calls
Hangs up on: busy signal, time-out, or touch tone command
Network remote speaker volume control
Automatic Gain Control (AGC) to automatically increase ring volume to compensate for ambient noise
Diagnostics for testing microphone and horn driver
Programmable pre-page alert tone
Enhanced Weather Protection (EWP), EWP products are designed to meet IP66 Ingress Protection Rating, see DOD 859
